Package Information
CAD Model: View CAD Model
Pkg. Type: PQFN
Pkg. Code: LIP
Lead Count (#): 39
Pkg. Dimensions (mm): 6.0 x 5.0 x 0.76
Pitch (mm): 0.5

Environmental & Export Classifications
Moisture Sensitivity Level (MSL) 3
Pb (Lead) Free Exempt
ECCN (US) EAR99
HTS (US) 8542.39.0090

Product Attributes
Lead Count (#) 39
Carrier Type Reel
Moisture Sensitivity Level (MSL) 3
Bias Voltage Range (V) 3.135 - 3.465
Pb (Lead) Free Exempt
Pb Free Category Pb-Free 100% Matte Tin Plate w/Anneal-e3
Country of Assembly MALAYSIA, THAILAND
Country of Wafer Fabrication TAIWAN
Input Voltage (Max) (V) 16
Input Voltage (Min) (V) 3
Length (mm) 6
MOQ 3000
Output Current (Max) [Rail 1] (A) 90
Parametric Category Smart Power Stages
Pitch (mm) 0.5
Pkg. Dimensions (mm) 6.0 x 5.0 x 0.76
Pkg. Type PQFN
Qualification Level Standard
Switching Frequency (KHz) 1.25 - 1.25
Temp. Range (℃) -40 to +85℃
Thickness (mm) 0.76
Width (mm) 5
